Main Features
- Eyepiece supports diopter adjustment
- Objective lens supports focus adjustment
- Supports IR illuminator in the 820–980nm wavelength range
- Auto shut-off function when helmet is flipped up
- Supports TF card storage, capacity ≥128GB
- Independent monocular system, each monocular can be used separately
- Single tube auto-standby at 90° flip, other side remains operational
- Flip-up design with damping to prevent flapping
- Powered by CR123A or 16340 battery, external battery pack supported
- Appearance modeled after PVS-31 (final design based on engineering drawings)
- Battery pack includes integrated compass
- Image overlay supports compass and battery status display
| Technical Specifications | |
| CMOS Sensor | |
| Resolution | 1920 (H) × 1080 (V) |
| Pixel Size | 4.0μm × 4.0μm |
| Optical Format | 1/1.8" |
| Sensitivity | 10800 mV/lux-sec |
| Operating Temperature | -30℃ ~ +85℃ |
| OLED Display | |
| Specification | |
| Resolution | 1920 (H) × 1080 (V) |
| Display Type | Micro OLED |
| Imaging Format | 1080×1080 inner circular display with black borders |
| Color Gamut | 85% NTSC |
| Contrast Ratio | >10,000:1 |
| Refresh Rate | 90 Hz |
| Operating Temperature | -20℃ ~ +85℃ |
| Optical Parameters | |
| Specification | |
| Objective Field of View | 25° |
| Focus Range | 250mm – ∞ |
| Eyepiece Field of View | 25° |
| Eye Relief | 30 mm |
| Pupil Diameter | 6 mm |
| IPD Adjustment Range | 50–80 mm |
| System Parameters | |
| Input Voltage | 2.6V – 4.2V |
| Display Power Consumption | ≤2.5W |
| Optical Axis Parallelism | <0.1° |
| Operating Temperature | -20℃ ~ +50℃ |
| Waterproof Rating | IP65 |
